Mechanical and damping performances of TPMS lattice metamaterials fabricated by laser powder bed fusion

Time：2024-08-12　　　Hits：997

Title: Mechanical and damping performances of TPMS lattice metamaterials fabricated by laser powder bed fusion

DOI: https://doi.org/10.1007/s41230-024-4026-5

*Yan-peng Wei, Huai-qian Li, Jing-jing Han, Ying-chun Ma, Hao-ran Zhou, Jing-chang Cheng, Jian Shi, Zhi-quan Miao, Bo Yu, and Feng Lin

Corresponding author:

*Yan-peng Wei

Male, born in 1990, Ph. D., Senior Engineer. His research interests mainly focus on the special alloy design, metallic lattice structures preparation and additive manufacturing process development.

E-mail: wyp20@mails.tsinghua.edu.cn

Abstract:

Lattice metamaterials based on three-period minimum surface (TPMS) are an effective means to achieve lightweight and high-strength materials which are widely used in various fields such as aerospace and ships. However, its vibration and noise reduction, and damping properties have not been fully studied. Therefore, in this study, the TPMS structures with parameterization were designed by the method of surface migration, and the TPMS structures with high forming quality was manufactured by laser powder bed fusion (LPBF). The mechanical properties and energy absorption characteristics of the beam and TPMS structures were studied and compared by quasi-static compression. The modal shapes of the beam lattice structures and TPMS structures were obtained by the free modal analysis, and the damping properties of two structures were obtained by modal tests. For the two structures after heat treatment with the same porosity of 70%, the yield strength of the beam lattice structure reaches 40.76 MPa, elastic modulus is 20.38 GPa, the energy absorption value is 32.23 MJ·m⁻³, the damping ratio is 0.52%. The yield strength, elastic modulus, energy absorption value and damping ratio of the TPMS structure are 50.74 MPa, 25.37 GPa, 47.34 MJ·m⁻³, and 0.99%, respectively. The results show that TPMS structures exhibit more excellent mechanical properties and energy absorption, better damping performance, and obvious advantages in structural load and vibration and noise reduction compared with the beam lattice structures under the same porosity.

Free full text: https://link.springer.com/article/10.1007/s41230-024-4026-5

If you'd like to learn more, please get it free at the following website:

https://www.springer.com/journal/41230 or

http://www.foundryworld.com/en/indexzhong.php/zazhishe/chinaguokan/type/3

Scan the QR code to download the papers published by China Foundry journal from 2020 to 2024
